Single Stage Hammer Crusher

Description of Single- Stage Hammer Crusher:
Our PCF series single-stage hammer crusher is typically used in cement industry to crush mineral materials whose compressive strength is no more than 200MPa, such as limestone, gypsum, coal, malm, shale, and more.

It has features of big crushing ratio, simple structure, reliable performance, convenient maintenance, low operation costs, and that.


Technical Parameters of PCF Series Single- Stage Hammer Crusher:

Model Feeding Size (mm) Discharge size (mm) Max. Feeding Size (mm) Rotor Diameter (mm) Rotor Length (mm) Production Capacity (t/h) Motor Power (kw) Weight (Excluding motor) (t)
PCF-1412 1290x1320 ≤25 600x600x900 1420 1200 80-130 130-190 23.5
PCF-1616 1500x1785 ≤25 800x800x1000 1650 1630 130-240 250-350 43.3
PCF-1818 1750x1840 ≤25 900x900x1200 1850 1730 240-350 400-560 70
PCF-2018 2268x2130 ≤25 1000x1000x1000 2020 1820 350-450 630-710 89
PCF-2022 2100x2380 ≤25 1000x1000x1500 2020 2230 400-600 630-800 128

Note: Parameters in the form are only for reference, and specific ones should refer to the particular contract.

As a professional manufacturer and supplier of single-stage hammer crusher in China, Jiangsu Pengfei Group Co., Ltd can also provide you with various other machines, such as air tank pulse bag dust filter, electric precipitator, cement production line, cement grinding plant, industrial kiln and furnace, grinding equipment, crushing equipment, environmental protection equipment, cooling equipment, drying equipment, compound fertilizer equipment, packing machine, chemical equipment and electrical control system. Most of our products have passed the certification of ISO9000 and CE, and they have been quite popular among customers from as many as 60 countries and districts such as Germany, Russia, Brazil, Egypt, Japan, South Korea, Bengal, Pakistan, Turkey, Vietnam, South Africa, Columbia, Bolivia, etc. If you need single-stage hammer crusher, please don't hesitate to contact us.
